Freescale Semiconductor FlexRay MFR4310 - Figure 3-39. Timer 2 Configuration Register 0 (TI2 CR0); Figure 3-40. Timer 2 Configuration Register 1 (TI2 CR1); Table 3-48. TI2 CR0 Field Descriptions

FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
Freescale Semiconductor 107
3.3.2.40 Timer 2 Configuration Register 0 (TI2CR0)
The content of this register depends on the value of the T2_CFG bit in the Timer Configuration and Control
Register (TICCR). For a detailed description of timer T2, refer to Section 3.4.17.2, “Absolute / Relative
Timer T2”.
NOTE
If timer T2 is configured as an absolute timer and the application modifies
the values in this register while the timer is running, the change becomes
effective immediately and timer T2 expires according to the changed values.
If timer T2 is configured as a relative timer and the application changes the
values in this register while the timer is running, the change becomes
effective when the timer has expired according to the old values.
3.3.2.41 Timer 2 Configuration Register 1 (TI2CR1)
0x0060 Write: Any Time
1514131211109876543210
R0 0
T2_CYC_VAL
00
T2_CYC_MSK
W
R
T2_MTCNT[31:16]
W
Reset0000000000000000
Figure 3-39. Timer 2 Configuration Register 0 (TI2CR0)
Table 3-48. TI2CR0 Field Descriptions
Field Description
Fields for absolute timer T2 (TICCR[T2_CFG] = 0)
13–8
T2_CYC_VAL
Timer T2 Cycle Filter Value — This field defines the cycle filter value for timer T2.
5–0
T2_CYC_MSK
Timer T2 Cycle Filter Mask — This field defines the cycle filter mask for timer T2.
Fields for relative timer T2 (TICCR[T2_CFG] = 1)
15–0
T2_MTCNT[31:16]
Timer T2 Macrotick High Word — This field defines the high word of the macrotick count for timer T2.
0x0062 Write: Any Time
1514131211109876543210
R0 0
T2_MTOFFSET
W
R
T2_MTCNT[15:0]
W
Reset0000000000000000
Figure 3-40. Timer 2 Configuration Register 1 (TI2CR1)
