Freescale Semiconductor FlexRay MFR4310 - Memory Map; Table 2-1. MFR4310 Device Memory Map after Reset

Device Overview
MFR4310 Reference Manual, Rev. 2
32 Freescale Semiconductor
2.3.1 Memory Map
Table 2-1 shows the MFR4310 device memory map.
Table 2-1. MFR4310 Device Memory Map After Reset
address (Hex) Module Registers
Size
(bytes)
0x0000–0x000E FlexRay
1
1
For detailed information on the MFR4310 FlexRay module registers, see Chapter 3, “FlexRay Module (FLEXRAYV4).
Configuration and Control Registers 16
0x0010–0x0012 FlexRay Reserved 4
0x0014–0x0026 FlexRay Interrupt and Error Handling Registers 20
0x0028–0x003E FlexRay Protocol Status Registers 24
0x0040–0x0044 FlexRay Sync Frame Counter and Table Registers 6
0x0046–0x004A FlexRay Sync Frame Filter Registers 6
0x004C–0x0058 FlexRay Network Management Vector Registers 14
0x005A–0x0062 FlexRay Timer Configuration Registers 10
0x0064–0x0066 FlexRay Slot Status Configuration Registers 4
0x0068–0x007E FlexRay Slot Status and Slot Status Counter Registers 24
0x0080–0x0082 FlexRay MTS Generation Registers 4
0x0084 FlexRay Shadow Buffer Configuration Register 2
0x0086–0x008A FlexRay Receive FIFO — Configuration 6
0x008C–0x008E FlexRay Receive FIFO — Status 4
0x0090–0x009A FlexRay Receive FIFO — Filter 12
0x009C, 0x009E FlexRay Dynamic Segment Status Registers 4
0x00A0–0x00DE FlexRay Protocol Configuration Registers 64
0x00E0–0x00E2 CRG
2
2
For detailed information on the MFR4310 CRG module registers, see Chapter 6, “Clocks and Reset Generator (CRG)”.
Clock and Reset Generation Registers 4
0x00E4–0x00EE FlexRay Reserved 12
0x00F0–0x00FE PIM
3
3
For detailed information on the MFR4310 PIM module registers, see Chapter 4, “Port Integration Module (PIM)”.
Part ID, ASIC Version Number, and Interface Pin Drive Strength and
Pullup/pulldown Control and Enable Registers
16
0x0100–0x01FE FlexRay Message Buffers Configuration, Control, Status (Message Buffer 0–31) 256
0x0200–0x02FE FlexRay Message Buffers Configuration, Control, Status (Message Buffer 32–63) 256
0x0300–0x03FE FlexRay Message Buffers Configuration, Control, Status (Message Buffer 64–95) 256
0x0400–0x04FE FlexRay Message Buffers Configuration, Control, Status (Message Buffer 96–127) 256
0x0500–0x07FE FlexRay Reserved 768
0x0800–0x1FFE FlexRay Message Buffers and FIFO Frame Header/Offset/Status/Data 6144
