FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
Freescale Semiconductor 89
3.3.2.16 Channel A Status Error Counter Register (CASERCR)
This register provides the channel status error counter for channel A. The protocol engine generates a slot
status vector for each static slot, each dynamic slot, the symbol window, and the NIT. The slot status vector
contains the four protocol related error indicator bits vSS!SyntaxError, vSS!ContentError, vSS!BViolation,
and vSS!TxConflict. The FlexRay module increments the status error counter by 1 if, for a slot or segment,
at least one error indicator bit is set to 1. The counter wraps around after it has reached the maximum value.
For more information on slot status monitoring, see Section 3.4.18, “Slot Status Monitoring”.
3.3.2.17 Channel B Status Error Counter Register (CBSERCR)
This register provides the channel status error counter for channel B. The protocol engine generates a slot
status vector for each static slot, each dynamic slot, the symbol window, and the NIT. The slot status vector
contains the four protocol related error indicator bits vSS!SyntaxError, vSS!ContentError, vSS!BViolation,
and vSS!TxConflict. The FlexRay module increments the status error counter by 1 if, for a slot or segment,
at least one error indicator bit is set to 1. The counter wraps around after it has reached the maximum value.
For more information on slot status monitoring see Section 3.4.18, “Slot Status Monitoring”.
0x0024 Additional Reset: RUN Command
1514131211109876543210
R STATUS_ERR_CNT
W
Reset0000000000000000
Figure 3-15. Channel A Status Error Counter Register (CASERCR)
Table 3-23. CASERCR Field Descriptions
Field Description
15–0
STATUS_ERR_CNT
Channel Status Error Counter — This field provides the current value channel status error counter. The
counter value is updated within the first macrotick of the following slot or segment.
0x0026 Additional Reset: RUN Command
1514131211109876543210
R STATUS_ERR_CNT
W
Reset0000000000000000
Figure 3-16. Channel B Status Error Counter Register (CBSERCR)
Table 3-24. CBSERCR Field Descriptions
Field Description
15–0
STATUS_ERR_CNT
Channel Status Error Counter — This field provides the current channel status error count. The counter
value is updated within the first macrotick of the following slot or segment.
