3.3.2.9 Global Interrupt Flag and Enable Register (GIFER)
7
BSY
WMC
Protocol Control Command Write Busy — This status bit indicates the acceptance of the protocol control
command issued by the application via the POCCMD field. The FlexRay module sets this status bit when the
application has issued a protocol control command via the POCCMD field. The FlexRay module clears this
status bit when protocol control command was accepted by the PE.When the application issues a protocol
control command while the BSY bit is asserted, the FlexRay module ignores this command, sets the protocol
command ignored error flag PCMI_EF in the CHI Error Flag Register (CHIERFR), and does not change the value
of the POCCMD field.
0 Command write idle, command accepted and ready to receive new protocol command.
1 Command write busy, command not yet accepted, not ready to receive new protocol command.
Write Mode Command — This bit controls the write mode of the POCCMD field.
0 Write to POCCMD field on register write.
1 Do not write to POCCMD field on register write.
3–0
POCCMD
Protocol Control Command — The application writes to this field to issue a protocol control command to the
PE. The FlexRay module sends the protocol command to the PE immediately. While the transfer is running, the
BSY bit is set.
0000 ALLOW_COLDSTART — Immediately activate capability of node to cold start cluster.
0001 ALL_SLOTS — Delayed
1
transition to the all slots transmission mode.
0010 CONFIG — Immediately transition to the POC:config state.
0011 FREEZE — Immediately transition to the POC:halt state.
0100 READY, CONFIG_COMPLETE — Immediately transition to the POC:ready state.
0101 RUN — Immediately transition to the POC:startup start state.
0110 DEFAULT_CONFIG — Immediately transition to the POC:default config state.
0111 HALT — Delayed transition to the POC:halt state
1000 WAKEUP — Immediately initiate the wakeup procedure.
1001 reserved
1010 reserved
1011 reserved
1100 RESET
2
— Immediately reset the Protocol Engine.
1101 reserved
1110 reserved
1111 reserved
1
Delayed means on completion of current communication cycle.
2
Additional to FlexRay Communications System Protocol Specification, Version 2.1 Rev A
NOTE
After sending the RESET command, it is mandatory to execute the
command sequence described in Section 3.7.3, “Protocol Reset Command”
immediately, to reach the DEFAULT CONFIG state correctly.
0x0016 Write: Normal Mode
1514131211109876543210
R MIF PRIF CHIF
WUPIF
FNEBIF FNEAIF
RBIF TBIF
MIE PRIE CHIE
WUPIE
FNEBIE FNEAIE
RBIE TBIE
W
Reset0000000000000000
Figure 3-8. Global Interrupt Flag and Enable Register (GIFER)
Table 3-15. POCR Field Descriptions (Continued)
Field Description
