3.3.2.53 Receive FIFO B Read Index Register (RFBRIR)
This register provides the message buffer header index of the next available receive FIFO B entry that the
application can read.
NOTE
If the receive FIFO not empty flag FNEBIF is not set, the RDIDX field
points to a physical message buffer that contains invalid data. Only when
FNEBIF is set, does the message buffer indicated by RDIDX contain valid
data.
3.3.2.54 Receive FIFO Message ID Acceptance Filter Value Register
(RFMIDAFVR)
This register defines the filter value for the message ID acceptance filter of the selected receive FIFO. For
details on message ID filtering see Section 3.4.9.5, “Receive FIFO filtering”.
0x008E
1514131211109876543210
R00000000 RDIDX
W
Reset0000000000000000
Figure 3-52. Receive FIFO B Read Index Register (RFBRIR)
Table 3-64. RFBRIR Field Descriptions
Field Description
7–0
RDIDX
Read Index — This field provides the message buffer header index of the next available receive FIFO entry that
the application can read. The FlexRay module increments this index when the application writes to the FNEBIF
flag in the Global Interrupt Flag and Enable Register (GIFER).The index wraps back to the first message buffer
header index if the end of the FIFO was reached.
0x0090 Write: POC:config
1514131211109876543210
R
MIDAFVAL
W
Reset0000000000000000
Figure 3-53. Receive FIFO Message ID Acceptance Filter Value Register (RFMIDAFVR)
Table 3-65. RFMIDAFVR Field Descriptions
Field Description
15–0
MIDAFVAL
Message ID Acceptance Filter Value — Filter value for the message ID acceptance filter.
