3.3.2.62.13 Protocol Configuration Register 12 (PCR12)
3.3.2.62.14 Protocol Configuration Register 13 (PCR13)
3.3.2.62.15 Protocol Configuration Register 14 (PCR14)
3.3.2.62.16 Protocol Configuration Register 15 (PCR15)
3.3.2.62.17 Protocol Configuration Register 16 (PCR16)
0x00B8 Write: POC:config
1514131211109876543210
R
allow_passive_to_active key_slot_header_crc
W
Reset0000000000000000
Figure 3-73. Protocol Configuration Register 12 (PCR12)
0x00BA Write: POC:config
1514131211109876543210
R
first_minislot_action_point_offset static_slot_after_action_point
W
Reset0000000000000000
Figure 3-74. Protocol Configuration Register 13 (PCR13)
0x00BC Write: POC:config
1514131211109876543210
R
rate_correction_out listen_timeout[20:16]
W
Reset0000000000000000
Figure 3-75. Protocol Configuration Register 14 (PCR14)
0x00BE Write: POC:config
1514131211109876543210
R
listen_timeout[15:0]
W
Reset0000000000000000
Figure 3-76. Protocol Configuration Register 15 (PCR15)
0x00C0 Write: POC:config
1514131211109876543210
R
macro_initial_offset_b noise_listen_timeout[24:16]
W
Reset0000000000000000
Figure 3-77. Protocol Configuration Register 16 (PCR16)
