communication cycle. The Symbol Window related status bits STCB, SBVB, SSEB, MTB, STCA, SBVA,
SSEB, and MTA are updated by the FlexRay module after the end of the symbol window and before the
end of the current communication cycle. If no symbol window is configured, the symbol window related
status bits remain in their reset state. The clock synchronization related CLKCORRFAILCNT is updated
by the FlexRay module after the end of the static segment and before the end of the current communication
cycle.
Table 3-27. PSR2 Field Descriptions
Field Description
15
NBVB
NIT Boundary Violation on Channel B — protocol related variable: vSS!BViolation for NIT on channel B
This status bit is set when there was some media activity on the FlexRay bus channel B at the end of the NIT.
0 No such event
1 Media activity at boundaries detected
14
NSEB
NIT Syntax Error on Channel B — protocol related variable: vSS!SyntaxError for NIT on channel B
This status bit is set when a syntax error was detected during NIT on channel B.
0 No such event
1 Syntax error detected
13
STCB
Symbol Window Transmit Conflict on Channel B — protocol related variable: vSS!TxConflict for symbol
window on channel B
This status bit is set if there was a transmission conflict during the symbol window on channel B.
0 No such event
1 Transmission conflict detected
12
SBVB
Symbol Window Boundary Violation on Channel B — protocol related variable: vSS!BViolation for symbol
window on channel B
This status bit is set if there was some media activity on the FlexRay bus channel B at the start or at the end of
the symbol window.
0 No such event
1 Media activity at boundaries detected
11
SSEB
Symbol Window Syntax Error on Channel B — protocol related variable: vSS!SyntaxError for symbol window
on channel B
This status bit is set when a syntax error was detected during the symbol window on channel B.
0 No such event
1 Syntax error detected
10
MTB
Media Access Test Symbol MTS Received on Channel B — protocol related variable: vSS!ValidMTS for
Symbol Window on channel B
This status bit is set if the Media Access Test Symbol MTS was received in the symbol window on channel B.
0 No such event
1 MTS symbol received
9
NBVA
NIT Boundary Violation on Channel A — protocol related variable: vSS!BViolation for NIT on channel A
This status bit is set when there was some media activity on the FlexRay bus channel A at the end of the NIT.
0 No such event
1 Media activity at boundaries detected
8
NSEA
NIT Syntax Error on Channel A — protocol related variable: vSS!SyntaxError for NIT on channel A
This status bit is set when a syntax error was detected during NIT on channel A.
0 No such event
1 Syntax error detected
7
STCA
Symbol Window Transmit Conflict on Channel A — protocol related variable: vSS!TxConflict for symbol
window on channel A
This status bit is set if there was a transmission conflicts during the symbol window on channel A.
0 No such event
1 Transmission conflict detected
