3.3.2.62.28 Protocol Configuration Register 27 (PCR27)
3.3.2.62.29 Protocol Configuration Register 28 (PCR28)
3.3.2.62.30 Protocol Configuration Register 29 (PCR29)
3.3.2.62.31 Protocol Configuration Register 30 (PCR30)
0x00D6 Write: POC:config
1514131211109876543210
R
micro_per_cycle_max[15:0]
W
Reset0000000000000000
Figure 3-88. Protocol Configuration Register 27 (PCR27)
0x00D8 Write: POC:config
1514131211109876543210
R
dynamic_slot
_idle_phase
macro_after_offset_correction
W
Reset0000000000000000
Figure 3-89. Protocol Configuration Register 28 (PCR28)
0x00DA Write: POC:config
1514131211109876543210
R
extern_offset_
correction
minislots_max
W
Reset0000000000000000
Figure 3-90. Protocol Configuration Register 29 (PCR29)
0x00DC Write: POC:config
1514131211109876543210
R000000000000
sync_node_max
W
Reset0000000000000000
Figure 3-91. Protocol Configuration Register 30 (PCR30)
