Freescale Semiconductor FlexRay MFR4310 - Page 122

FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
122 Freescale Semiconductor
macro_initial_offset_a pMacroInitialOffset[A]
MT 6
macro_initial_offset_b pMacroInitialOffset[B]
MT 16
macro_per_cycle gMacroPerCycle
MT 10
macro_after_first_static_slot gMacroPerCycle - gdStaticSlot
MT 1
macro_after_offset_correction gMacroPerCycle - gOffsetCorrectionStart
MT 28
max_without_clock_correction_fatal gMaxWithoutClockCorrectionFatal
cyclepairs 8
max_without_clock_correction_passive gMaxWithoutClockCorrectionPassive
cyclepairs 8
minislot_exists gNumberOfMinislots!=0 0 1 bool 9
minislots_max gNumberOfMinislots - 1
minislot 29
number_of_static_slots gNumberOfStaticSlots
static slot 2
offset_correction_start gOffsetCorrectionStart
MT 11
payload_length_static gPayloadLengthStatic
2-bytes 19
max_payload_length_dynamic pPayloadLengthDynMax
2-bytes 24
first_minislot_action_point_offset max(gdActionPointOffset,
gdMinislotActionPointOffset) - 1
MT 13
allow_halt_due_to_clock pAllowHaltDueToClock
bool 26
allow_passive_to_active pAllowPassiveToActive
cyclepairs 12
cluster_drift_damping pClusterDriftDamping
μT24
comp_accepted_startup_range_a pdAcceptedStartupRange -
pDelayCompensationChA
μT22
comp_accepted_startup_range_b pdAcceptedStartupRange -
pDelayCompensationChB
μT26
listen_timeout pdListenTimeout - 1
μT 14/15
key_slot_id pKeySlotId
number 18
key_slot_used_for_startup pKeySlotUsedForStartup
bool 11
key_slot_used_for_sync pKeySlotUsedForSync
bool 11
latest_tx gNumberOfMinislots - pLatestTx
minislot 21
sync_node_max gSyncNodeMax
number 30
micro_initial_offset_a pMicroInitialOffset[A]
μT20
micro_initial_offset_b pMicroInitialOffset[B]
μT20
micro_per_cycle pMicroPerCycle
μT 22/23
micro_per_cycle_min pMicroPerCycle - pdMaxDrift
μT 24/25
micro_per_cycle_max pMicroPerCycle + pdMaxDrift
μT 26/27
micro_per_macro_nom_half round(pMicroPerMacroNom / 2)
μT7
offset_correction_out pOffsetCorrectionOut
μT9
rate_correction_out pRateCorrectionOut
μT14
single_slot_enabled pSingleSlotEnabled
bool 10
wakeup_channel pWakeupChannel see Table 3- 74 10
wakeup_pattern pWakeupPattern
number 18
decoding_correction_a pDecodingCorrection +
pDelayCompensation[A] + 2
μT19
Table 3-73. Protocol Configuration Register Fields (Continued)
Name Description
1
Min Max Unit PCR
