12.1 Standard Model
12-14
■ Standard-model, Three-phase 400 V (460 V) class series (HHD-mode: 0.4 kW to 3.7 kW)
Item Specifications
Type (FRN_ _ _ _E2S-4) 0002 0004 0006 0007 0012
Nominal applied motor (kW) [HP]
(Output rating)
*1
0.4
[1/2]
0.75
[1]
1.5
[2]
2.2
[3]
3.7
[5]
Output ratings
Rated capacity (kVA) *2
1.1
[1.2]
1.9
[2.0]
3.2
[3.3]
4.2
[4.4]
6.9
[7.2]
Rated voltage (V) *
3
Three-phase 380 to 480 V (with AVR function)
Rated current (A) *4 1.5 2.5 4.2 5.5 9.0
Overload capability 150%-1 min, 200%-0.5 s
Input power
Voltage, frequency Three-phase 380 to 480 V, 50/60 Hz
Allowable voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less) *6,
Frequency: +5 to -5%
Rated input current *7
(w/o DCR) (A)
1.7 3.1 5.9 8.2 13.0
(with DCR) (A) 0.85 1.6 3.0 4.4 7.3
Required capacity
(with DCR) (kVA) *8
0.6 1.2 2.1 3.1 5.1
Braking
Torque (%)
*9
100% 70% 40%
DC braking
Braking starting frequency: 0.0 to 60.0 Hz, Braking time: 0.0 to 30.0 s,
Braking level: 0 to 100%
Braking transistor Built-in as standard
Minimum resistance value (Ω)
200 160 130
Braking resistor Separately mounted option
DC reactor (DCR) Separately mounted option
Applicable safety standards IEC/EN61800-5-1: 2007
Enclosure (IEC60529) IP20, UL open type
Cooling method Fan cooling
Weight / Mass (kg) [lbs]
1.2
[2.6]
1.5
[3.3]
1.5
[3.3]
1.6
[3.5]
1.9
[4.2]
Note: A box () in the above table replaces GA, GB or C depending on the model.
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 440 V (460 V).
*3 Output voltage cannot exceed the power supply voltage.
*4 Setting the carrier frequency (F26) to the following value or above requires current derating.
HHD spec of type FRN0002E2■-4 to FRN0012E2■-4: 8 kHz,
HHD spec of type FRN0022E2■-4 to FRN0168E2■-4: 10 kHz,
HHD spec of type FRN0203E2■-4 to FRN0590E2■-4: 6 kHz,
If reduction is necessary, for details, refer to Figure 10.4-1 in Chapter 10 “10.4.2 Guideline for selecting
inverter drive mode and capacity.”
*6
67 ×
(V) voltage average phase-Three
(V) voltage Min. - (V) voltage Max.
=(%) unbalance Voltage
(IEC 61800-3)
If the unbalance ratio is 2% to 3%, use an optional AC reactor (ACR).
*7 This specification is an estimated value to be applied when the power supply capacity is 500 kVA (Inverter
capacity × 10 when the capacity exceeds 50 kVA) and the power supply with %X = 5% is connected. When
applying with motors of 75 kW (100 HP) or above, a DC reactor (DCR) should be used.
*8 This specification applies when a DC reactor (DCR) is used.
*9 Average braking torque for the motor running alone. It depends on the efficiency of the motor.
