RX100 S8
Upgrade and Maintenance Manual 131
Hard disk drives / solid state drives
Figure 63: Disconnecting SAS cables
Ê Disconnect the two SAS cables from the SAS expander board.
Figure 64: Removing the SAS expander board (A)
Ê Remove the two screws (see circles).
