52 Upgrade and Maintenance Manual
RX100 S8
Basic hardware procedures
4.5 Reassembling
V CAUTION!
●
Before attaching the covers, make sure no unnecessary parts or tools
are left inside the server.
●
The top cover must be replaced as soon as possible for purposes of
cooling, to comply with EMC regulations (regulations regarding
electromagnetic compatibility) and to prevent fires.
●
For further safety information, please refer to chapter "Important
information" on page 31.
4.5.1 Installing the top cover
Figure 7: Attaching the top cover
Ê Place the top cover on the server (1).
Ê Push the top cover as far as it will go in the direction of the arrow (2) until it
clicks in.
