RX100 S8
Upgrade and Maintenance Manual
241
Fron
t pane
l
13.3.3
Inst
alling the front p
anel on QRL
Figure 180: Installing t
he front p
anel (A)
Ê
Thr
ead the front pane
l
cable through the opening.
Figure 181: Installing t
he front p
anel (B)
Ê
Position the front panel on the ear
.
Ê
Fas
ten the front panel
with two screws (see figure
178
).
