266
Upgrade and Mai
ntenance Manual
RX100
S8
System board and co
mponents
14.5.1.2
Remo
ving the defective system b
oard
Ê
Disconnect all cables from the system board.
Figure 200: Position of t
he screws
Ê
Remove the eight screws
from the system board.
265
267
