11.3 Replacing the heat sink
11.3.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing a riser module" on page 58
11.3.2 Removing the defective heat sink
Ê Remove the heat sink as described in section "Removing the heat sink" on
page 213.
Ê Remove the residual thermal paste from the processor surface.
Ê Clean the processor surface using a lint-free cloth.
11.3.3 Installing the new heat sink
Ê Remove the protective cover on the underside of the heat sink.
V CAUTION!
Do not touch the thermal paste on the underside of the heat sink.
Ê Install the heat sink as described in section "Installing the heat sink" on
page 218.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
