Fujitsu PRIMERGY RX100 S8 Upgrade And Maintenance Manual

RX100 S8 Upgrade and Maintenance Manual 227
Optical disk drive
12.3 Removing the ODD
12.3.1 Preliminary steps
Ê "Removing backup and optical disk media" on page 66
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
12.3.2 Removing the ODD
Figure 162: Disconnecting the cables from the ODD
Ê Disconnect the ODD power cable and the SATA cable from the ODD.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: Torx Plus 6 screw driver

Fujitsu PRIMERGY RX100 S8 Specifications

General

CPU Family	Intel Xeon
Memory Type	DDR3
Memory Slots	4
Maximum Memory	32 GB
Network Interface	Gigabit Ethernet
Processor	Intel Xeon E3-1200 v2
Storage	SAS, SATA
RAID Support	RAID 0, 1, 10
Drive Bays	4 x 3.5" or 8 x 2.5"
