Fujitsu PRIMERGY RX100 S8 - Installing the ODD; Preliminary Steps

RX100 S8 Upgrade and Maintenance Manual 223
Optical disk drive
2.5-inch HDD configuration
Figure 155: Position of the ODD bay - example 2.5-inch HDD configuration
Figure 156: Routing ODD cables - example 2.5-inch HDD configuration
12.2 Installing the ODD
12.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Torx Plus 6 screw driver
