150 Upgrade and Maintenance Manual RX100 S8
Fans
8.1.1 Numbering of the fan modules
Figure 82: Numbering of the fan modules
8.2 Replacing a defective fan module
8.2.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Locating the defective component" on page 45
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
