RX100 S8
Upgrade and Maintenance Manual 295
Appendix
16.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the server to the mains" on page 55
Ê Connect a keyboard, mouse and display to the server.
Ê Switch on the server as described in section "Switching on the server" on
page 57.
Field Replaceable Units (FRU)
Component Notes
System board no TPM, UFM or expansion cards installed
CPU with CPU heat sink
1 memory module installed in DIMM slot 1A
Front panel module
Power supply unit
Table 5: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 6: Minimum startup configuration - cables
