RX100 S8
Upgrade and Maintenance Manual 99
Power supply
Figure 30: Installing the cable tie
Ê Push the cable tie into the corresponding hole until it clicks in.
6.3.1.4 Concluding steps
Ê "Connecting the server to the mains" on page 55
6.3.2 Removing a hot-plug power supply unit
I Note for servers using CMA (Cable Management Arm)
Regarding of removing power supply units, additional tasks are needed,
due to an interference between CMA stopper and the power supply units.
Ê Unlock the CMA stopper.
Ê Remove the CMA stopper with the mounted crossbar.
Ê Support the CMA stopper, the crossbar and the CMA including cables
with your right hand.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
