Fujitsu PRIMERGY RX100 S8 - Memory Sequence; Population Rules

RX100 S8 Upgrade and Maintenance Manual 205
Main memory
10.1.1 Memory sequence
10.1.1.1 Population rules
– Populate memory slot 1 / channel A (DIMM 1A) first.
– Within all channels memory slot 1 must be populated prior to slot 2.
– Install memory modules within a channel in descending order of capacity:
higher capacity in slot 1, lower capacity in slot 2.
Channel A B
Slot ID 2A 1A 2B 1B
DIMM #
1(1)
2(1) (2)
3 (3) (1) (2)
4 (3) (1) (4) (2)
Table 4: Mounting order
