168 Upgrade and Maintenance Manual
RX100 S8
Expansion cards and backup units
Installing the secondary SFP+ transceiver module
Figure 103: Installing the secondary SFP+ transceiver module
Ê If applicable, install the secondary SFP+ transceiver module accordingly.
9.3.2 Removing an SFP+ transceiver module
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
