Fujitsu PRIMERGY RX100 S8 Upgrade And Maintenance Manual

140 Upgrade and Maintenance Manual RX100 S8
Hard disk drives / solid state drives
7.3.2 Installing 3.5-inch HDD modules
7.3.2.1 Preliminary steps
Ê Locate the correct drive bay as described in section "3.5-inch HDD
configurations" on page 139.
7.3.2.2 Removing a 3.5-inch HDD dummy module
Figure 75: Removing a 3.5-inch dummy module
Ê Press both tabs together (1) and pull the dummy module out of its bay (2).
V CAUTION!
Save the dummy module for future use.
Always replace dummy modules into unused HDD bays to comply with
applicable EMC regulations and satisfy cooling requirements.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY RX100 S8 Specifications

General

CPU Family	Intel Xeon
Memory Type	DDR3
Memory Slots	4
Maximum Memory	32 GB
Network Interface	Gigabit Ethernet
Processor	Intel Xeon E3-1200 v2
Storage	SAS, SATA
RAID Support	RAID 0, 1, 10
Drive Bays	4 x 3.5" or 8 x 2.5"
