RX100 S8
Upgrade and Maintenance Manual 215
Processo
Figure 147: Removing the processor
Ê Lift the processor carefully out of the processor socket.
V CAUTION!
Be careful not to touch or bend the spring contacts on the processor
socket.
11.2.4 Installing the new processor
Ê Remove the protective cap from the bottom side of the processor.
Figure 148: Installing the processor
Ê Insert the new processor carefully into the processor socket. Notice the
coding (see circles).
