Fujitsu PRIMERGY RX100 S8 - Connecting the BBU Cable to the BBU

186 Upgrade and Maintenance Manual RX100 S8
Expansion cards and backup units
9.5.1.2 Connecting the BBU cable to the BBU
V CAUTION!
Do not connect the cable using excessive force, the connector is weak.
Figure 121: Connecting the BBU cable
Ê Connect the BBU cable to the BBU.
V CAUTION!
Make sure that the connector side with the three dots is on the top (see
close-up). Otherwise you risk short-circuits.
