RX100 S8
Upgrade and Maintenance Manual 197
Expansion cards and backup units
9.5.3.4 Disconnecting the BBU cable from the BBU
Figure 136: Disconnecting the BBU cable from the BBU
Ê Disconnect the BBU cable from the BBU.
9.5.3.5 Concluding steps
Ê "Reassembling" on page 52
Ê "Connecting the server to the mains" on page 55
Ê "Switching on the server" on page 57
9.5.4 Removing an FBU
V CAUTION!
●
Dispose of used battery properly. Keep away from children.
●
Do not throw flash backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
