254 Upgrade and Maintenance Manual
RX100 S8
System board and components
Ê "Getting access to the component" on page 47
Ê Remove the riser module 1 as described in section "Removing a riser
module" on page 58.
14.4.1.2 Installing the TPM
Figure 193: TPM installation kit
Figure 194: Position on the system board
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
