RX100 S8 Upgrade and Maintenance Manual 173
Expansion cards and backup units
Ê "Enabling BitLocker functionality" on page 84
9.4.2 Removing an expansion card
9.4.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê Remove the corresponding riser module as described in section "Removing
a riser module" on page 58.
9.4.2.2 Removing the expansion card
Ê If necessary, disconnect the cables from the expansion card.
Figure 109: Removing the expansion card - example riser module 1
Ê Pull out the expansion card from the riser card slot.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
