RX100 S8
Upgrade and Maintenance Manual 255
System board and components
Figure 195: Inserting the TPM spacer on the system board
Ê Insert the TPM spacer into the hole on the system board.
Figure 196: TPM bit insert
Ê Attach the TPM bit insert or TPM module fixing tool (Japanese market) to a
bit screw driver.
