Concluding steps
▶
Connect all cables to the system board.
For the cable plan, see "Appendix B" on page 519
.
▶
Install all remaining system board components as shown in the related
sections:
▶
If applicable, install all M.2 SSDs, see "Installing the M.2 SSD" on
page 434
.
▶
If applicable, install the Dual microSD 64GB Enterprise, see "Installing
the Dual microSD 64GB Enterprise" on page 441.
▶
Memory modules: "Installing a memory module" on page 334.
Ensure that you reinstall each memory module in the slot it was
located before the replacement.
▶
Expansion cards: "Installing an expansion card" on page
299
.
If applicable, connect the riser card.
▶
If applicable, install the expander board, see "Installing the SAS expander
board" on page 268.
▶
Install the system fan module, see "Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66.
▶
Connect all external cables.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
System board and components
TX1330 M4 Upgrade and Maintenance Manual 457
