Introduction
1.4 Technical Support
The 7200 Antenna Control Unit (ACU) contains context-sensitive, on-line help that
is easily accessible from any menu or submenu in the system by simply pressing
the [HELP] key on the 7200 ACU's front panel. For operational problems, a
troubleshooting guide is provided in Appendix E of this manual.
If any questions or problems arise that are not addressed by the manual or the
online help (provided by pressing the [HELP] key), please contact our technical
support team.
1. Email us at LV_CustomerService@gdsatcom.com.
2. Phone us at (903) 295-1480.
1.5 Important Safety Information
1.5.1 Explanation of Safety Symbols
Symbol Explanation
Protective Earth/Ground Terminal
Caution, Risk of Electric Shock
Caution, Risk of Danger.
Consult accompanying documents.
1.5.2 Technical & Environmental Specifications
7 in H (17.8 cm) x 19 in W (48.3 cm) x 19 in D (48.3 cm)
ACU Mass 26 lbs (11.8 kg)
ACU Maximum Power 75 VA
ACU Maximum Operating Altitude 10,000 ft (3,048 m)
1.5.3 User Supplied Power Cord Requirements
If the factory supplied power cable for the ACU is not available, a user supplied
power cord may be used provided it meets the following criteria: #18 AWG, 10A.
The Belden 17742C/10 or equivalent power cord for example is recommended.
1-3
To Next Page
