By pressing the DSPL key on the Digital Operator, the operator can step to each of
the seven Function LEDS and its associated display/setting function:
FR
E
F F
O
UT
IOUT
Press
DSPL
Press
DSPL
MN
T
R
Press
D
SP
L
Pr
es
s
DSPL
F/R
L
O/RE
P
R
GM
Press
D
S
PL
Press
D
S
PL
Pr
es
s
DS
PL
Figure 4-6 Digital Operator Indicator and Key Description
TABLE 4-17 DIGITAL OPERATOR LED FUNCTION DESCRIPTIONS
Key Description
F
R
E
F
Frequency Reference Setting
Sets/Displays the GPD 315 operation speed (Hz).
FOUT
Output Frequency Monitor
Displays the output frequency (Hz) at which the GPD 315 is currently operating.
This is a monitor only function; the operator cannot change the displayed value by
use of the keypad.
IOUT
Output Current Monitor
Displays the level of the output current (Amps) that the GPD 315 is currently
producing. This is a monitor only function; the operator cannot change the displayed
value by use of the keypad.
MNTR
Monitor Selection
Pressing ENTER allows access to the various Monitor parameters, U-01 through U-
10. These are monitor only functions; the operator cannot change the displayed
value. Accessible during run command. See vendor literature for complete listing of
all monitor parameters.
F/R
FWD/REV Run Selection
Sets the rotation direction of the motor when a Run command is given by the Digital
Operator keypad. Display of For=forward run, rEu=reverse run.
LO/RE
Local/Remote Selection
This toggles between the Local (Digital Operator) and Remote (set by parameters
n003 & n004) modes of operation. This affects both the start/stop functions, as
well as the frequency reference. Local/Remote status cannot be changed using this
LED when a multi-function input terminal is set for Local/Remote (n050 through
n056 set for “17”).
PRGM
Parameter Programming
Selects or reads data using parameter number (nXXX). Data is displayed by pressing
the ENTER key, and can be changed by pressing the “up arrow” or “down arrow”
keys. Any changes can be saved by again pressing the ENTER key. Pressing the
DSPL key exits the Programming mode.
4-24
