Operation
5.8.6 Edit System Configuration Menu
WARNING
Any of the system configuration parameters may be viewed at any
time, but modifying these parameters after installation may cause
the ACU to malfunction.
The Edit system configuration... menu contains the following menus and function:
• Tracking Receiver Parameters…
• Tracking receiver setup...
• Steptrack defaults...
• Position encoder configuration...
• Motion limits...
• Position loop parameters...
• Built-in simulator setup...
• Set UTC date and time...
• Site data...
• RF/geometry
• Network configuration…
• Remote port configuration...
• ACU sync configuration
• User interface options...
• Tracking restoration options...
• Factory tests...
• Message printer options...
5.8.6.1 Tracking Receiver Parameters Menu
The parameters for the Tracking receiver parameters... menu will vary according to
the type of tracking being performed. Refer to Section 5.8.2.3.2 for a complete
listing and description of these parameters and procedures for changing them. If a
tracking receiver with serial link is being used, one of the following Remote port
configuration shells should be selected. If a Model 253 Receiver shell is selected,
Frequency [MHz], A/D Channel, and Bandwidth will be displayed. If a TRL shell is
selected, Frequency [MHz], RF input, and Attenuation [db] parameters will be
displayed. If a DTR Shell is selected, Frequency [MHz], RF Input, FFT Sample
Averaging, Filter Bandwidth and DTR Detection Type will be displayed under this
menu.
If none of these shell selections is made, an analog signal input is used. A/D
channel and Beacon parameters will be displayed.
