Operation
5.8.5.13 Firmware Version Information
Firmware version information shows the ACU firmware version information. This
allows General Dynamics personnel to determine which versions of firmware are
being used in the ACU. The information includes the ACU version, factory
configuration options, build time, printed circuit board (PCB) revision, complex
programmable logic device (CPLD) version, bootloader EEPROM version, and
network controller version. The 7200 ACU firmware has both a version number
and a configuration. The configuration is displayed on the line below the version
information as a 32 bit HEX coded label called “ACU-CONFIG”. The center column
defines the firmware configuration that is included when its respective bit is set to
a one. The third column lists what the HEX coded value would be assuming that
only one optional configuration was added to the standard factory 7200 ACU
firmware. It is possible to have multiple configurations combined together in the
same 7200 ACU firmware release.
TABLE 5-26 ACU-CONFIG Firmware Options
Configuration Bit Optional Firmware Configurations
Single Option HEX ACU-CONFIG
Code w/ VCPU Board
0 LSB Norad Tracking $80000001
1 Remove Star Tracking $80000002
2 GPIB (IEEE-488) Port $80000004
3 Moon Tracking $80000008
4 Table Tracking $80000010
5 Circular Pol/Linear Pol Switching $80000020
6 Fourth Axis $80000040
7 Dual Polarization Axis $80000080
8 Ka-Band Frequency Limit $80000100
9 Intelsat with Low Signal Alarm $80000200
10 Delay to Standby $80000400
11 Orbit Element Tracking $80000800
12 Sun Tracking $80001000
13 With Transmit CP_LP Control $80002000
14 With DMK_Stow Mode $80004000
15 With Redundant ACU $80008000
16 With 7200 Aux Drive Cabinet $80010000
17 With 7200 ACU Parameter Sync $80020000
18 - 30 Reserved for future configurations N/A
31 MSB With VCPU Board $80000000 ♦
♦ Denotes the standard firmware configuration for the 7200 Antenna Control Units.
5-49
