Installation
17 15 -
18 15 +
19 NC
20 14 -
21
14 +
22 11 -
23 11 +
24 10 -
25 10 +
26 9 -
27 9 +
28 8 -
29 8 +
30 7 -
31 7 +
32 6 -
33 6 +
34 NC
35 NC
36 NC
37 NC
4.3.8 Remote Communications Connections
Tables 4-12 and 4-13 provide the connections for the remote communication ports
to the 7200 ACU. Two independent Monitor and Control (M&C) protocols are
provided with the 7200 ACU:
1) Request/Command (RC) M&C Protocol – This protocol format is ASCII based;
the protocol is concise, yet includes all the commonly used commands for
operation. See General Dynamics Document # CG-6042.
2) Menu Tree M&C protocol – This protocol format is also ASCII based but is more
comprehensive. It includes all setup and operational commands as well as
some diagnostics. See General Dynamics Document # CG-6045.
Refer to Section 5.8.6.12, Remote Port Configuration, for additional interfaces.
The standard 7200 ACU is capable of EIA/TIA-232E, EIA/TIA-422B, and Ethernet
communications.
4-18
