General Dynamics 7200 User Manual

Operation
Tracking
initiation delay
[ms]
0
This parameter controls the delay between a tracking mode or target
change. Whenever the tracking mode is changed (except for returning to
Standby), or a new target is selected, the ACU waits for the amount of
time of this parameter before initiating tracking. Also, output 1 on ACU
terminal TB1 is closed and remains closed while tracking. This may be
used to drive a warning beacon, horn, etc. In addition, when changing
between targets or to or from manual mode, there is an additional one
second delay. This delay is used to open output 1 on terminal TB1 and then
close it again, which may be used to reset a horn with a fixed alarm time,
so that it will sound again. Setting this parameter to a value other than 0
disables the delay and output 1 is not driven.
The parameters under this menu may be changed by selecting the desired
parameter, and using the up and down arrow keys, toggling through the
preprogrammed choices. When the desired setting is highlighted, press the
[ENTER] key.
To save the changes, press [PRIOR] and answer yes when prompted to save the
changes.
5.8.6.16 Factory Tests
The Factory tests... menu contains tests that are used at the factory during system
testing. These tests are available to the user because some of these tests may be
useful in the field during troubleshooting.
5.8.6.16.1 Video Tests
These tests are used to examine the display for malfunctioning pixels, data lines,
etc.
The ACU must be in Standby, and the port performing the test must be at
Operator or Supervisor level. During the test, the [STOP]/[RESUME] keys are still
operational. To execute the Video test, use the following procedures.
1. From the Main menu..., select Edit system configuration..., Factory tests..., and
Video test.
2. If the ACU is not in Standby mode, a message will appear alerting the operator
to this fact and when the [ENTER] key is pressed, the ACU will return to the
menu.
If the ACU is in Standby mode, a warning message will appear to alert the user
that the display will be blanked for the test.
3. To begin the test, answer yes to the prompt and press [ENTER]. Note that the
[PRIOR] key may be pressed at any time to terminate the test.
5-80
