94
_____________________________________________________________________________________________
6.3 Program Setting State
______________________________________________________________________________________________
Test type: AC50 Hz
Test-voltage value: 1.5 kV
Upper-limit value: 20 mA
Lower-limit value: OFF
Test time: 10.0 s
Ramp-uptime:5.0s
Ramp-down time: OFF
(9) Setting test conditions in step 2
Set the conditions of the test to be conducted in step 2.
When the test conditions have been set, press the
ENTER
key to finalize the
settings. Then, proceed to the setting of step 3.
(10) Setting of step 3
Select
3
as the step number. Press the
ENTER
key, and proceed to the next
setting.
(11) Type of test performed in step 3
The test to be performed in step 3 is a withstand-voltage test. Therefore, the
W
key should be pressed. In addition, as the test is terminated in step 3,
select
OFF
using the
ON/OFF
key.
