185
_____________________________________________________________________________________________
10.3 RS-232C Command Reference
______________________________________________________________________________________________
Syntax
:MEMory:WITHstand:FILE? <data>
Response
syntax
<data1>,<data2>,<data3>,<data4>,<data5>,<data6>,<data7>
<data1>
Test type:
0
(AC50 Hz-withstand-voltage test),
1
(AC60 Hz-withstand-voltage test),
2
(DC-withstand-voltage test) (NR1)
<data2>
Test-voltage value:
0.20 to 5.00
(unit: kV, NR2)
<data3>
Upper-limit value:
0.1 to 100
(unit: mA, NR1 or NR2)
<data4>
Lower-limit value:
0
(OFF),
0.1 to 99.9
(unit: mA, NR2 or character data)
<data5>
Test time setting value:
0
(OFF),
0.3 to 999
(unit: s, NR1, NR2 or character data)
<data6>
Ramp-up time setting value:
0
(OFF),
0.1 to 99.9
(
unit: s, NR2 or character data)
<data7>
Ramp-down time setting value:
0
(OFF),
0.1 to 99.9
(unit: s, NR2 or character data)
Function
Queries the contents of the set-value memory for the withstand-voltage test number specified in
<data>.
Example
Queries the contents of memory file 1 for withstand-voltage tests.
Transmission :MEMory:WITHstand:FILE? 1
Response 0,1.20,5.0,0,20.0,5.0,0
Test type: AC50 Hz-withstand-voltage test; Test voltage: 1.2 kV;
Upper-limit value: 5 mA; Lower-limit value: OFF; Test time: 20.0 s;
Ramp-up time: 5.0 s; Ramp-down time: OFF
Error
An execution error occurs when file numbers other than 1 to 10 are specified.
Syntax
:MEMory:WITHstand:LOAD <data>
<data>
1to10
(NR1)
Function
Loads the data saved for the withstand-voltage test file numbers specified in <data>.
Example
Loads memory file 1 for withstand-voltage tests.
Transmission :MEMory:WITHstand:LOAD 1
Error
The execution of this command in a state other than the withstand-voltage mode READY state
causes an execution error.
The execution of this command in the insulation-resistance mode and program mode also causes
an execution error.
An execution error occurs when file numbers other than 1 to 10 are specified.
:MEMor
y
:WITHstand:FILE?
Queries the contents of the set-value memory for withstand-voltage tests.
:MEMor
y
:WITHstand:LOAD
Loads the set-value memory for withstand-voltage tests.
