192
_____________________________________________________________________________________________
10.3 RS-232C Command Reference
______________________________________________________________________________________________
Syntax
:MEASure:RESult:INSulation?
Response
syntax
<data1>,<data2>,<data3>,<data4>
<data1>
Measured voltage value (unit: V)
<data2>
Measured resistance value (unit: MΩ)
O.F.: 10000
U.F.: 0
<data3>
Test time elapsed (unit: s)
<data4>
Determination
Excluding determination: NR1 or NR2
Determination:
PASS
UFAIL
(UPPER FAIL)
LFAIL
(LOWER FAIL)
ULFAIL
(UPPER LOWER FAIL)
OFF
(Others)
(Character data)
Function
Queries the results of the preceding test. Returns the determination and valid values at
termination of the preceding test. The test results are updated upon termination of a new test.
Example
Queries the measured value for insulation-resistance test.
Transmission :MEASure:RESult:INSulation?
Response 500,100,10.0,PASS
Measured voltage value: 500 V; Measured current value: 100 MΩ;
Test time elapsed: 10.0 s; Determination: PASS
Syntax
:MEASure:INSulation:VOLTage?
Response
syntax
<data>
<data>
Insulation-resistance test measured voltage value (NR1)
Function
Queries the measured voltage value (unit: V) for insulation-resistance tests.
Example
Queries the measured voltage value for insulation-resistance tests.
Transmission :MEASure:INSulation:VOLTage?
Response 500
The measured voltage value is 500 V.
Error
The execution of this command in a state other than the TEST state causes an execution error.
:MEASure:RESult:INSulation?
Queries the insulation-resistance test result.
:MEASure:INSulation:VOLTa
g
e?
Queries the measured voltage value for insulation-resistance tests.
