10.3 RS-232C Command Reference
______________________________________________________________________________________________
Syntax
:MEMory:INSulation:FILE? <data>
<data>
1to10
(NR1)
Response
syntax
<data1>,<data2>,<data3>,<data4>,<data5>,<data6>
<data1>
Test type:
3
(insulation-resistance test)
<data2>
Test-voltage value:
50 to 1200
(unit: V, NR1)
<data3>
Upper-limit value:
0
(OFF),
0.10 to 9999
(unit: M
Ω
, NR1 or NR2)
<data4>
Lower-limit value:
0.10 to 9999
(unit: M
Ω
, NR1 or NR2)
<data5>
Test time setting value:
0
(OFF),
0.3 to 999
(unit: s, NR1 or NR2)
<data6>
Delay time setting value:
0
(OFF),
0.1 to 99.9
(unit: s, NR1 or NR2)
Function
Queries the content of setting value memory for the insulation-resistance file specified in <data>.
Example
Queries insulation-resistance test data to memory file 1.
Transmission :MEMory:INSulation:FILE? 1
Response 3,1000,0,100,5.0,1.0
Test type: insulation-resistance test; Test voltage: 1000 V;
Upper-limit value: OFF; Lower-limit value: 100 M
Ω
;
Test time: 5.0 s; Delay time: 1.0 s
Error
An execution error occurs when file numbers other than 1 to 10 are specified.
Syntax
:MEMory:INSulation:LOAD <data>
<data>
1to10
(NR1)
Function
Loads the data saved for the insulation-resistance file specified in <data>.
Example
Loads insulation-resistance test data to memory file 1.
Transmission :MEMory:INSulation:LOAD 1
Error
The execution of this command in a state other than the insulation-resistance mode READY state
causes an execution error.
The execution of this command in the withstand-voltage mode and program mode also causes an
execution error.
An execution error occurs when file numbers other than 1 to 10 are specified.
:MEMor
y
:INSulation:FILE?
Queries the content of data saved for insulation-resistance tests.
:MEMor
y
:INSulation:LOAD
Loads data saved for insulation-resistance tests.
