# Configure static RPs on all S9300s. The configurations of S9300-B, S9300-C, S9300-D, and
S9300-E are similar to configuration on S9300-A, and are not mentioned here.
NOTE
If you enter preferred to the right of static-rp X.X.X.X, the static RP is selected as the RP in the PIM-SM
domain.
[S9300-A] pim
[S9300-A-pim] static-rp 192.168.2.2
Step 6 Configure the BSR boundary on the interface connecting S9300-D to the Internet.
[S9300-D] interface vlanif 104
[S9300-D-Vlanif104] pim bsr-boundary
[S9300-D-Vlanif104] quit
Step 7 Configure the range of SSM group addresses.
# Set the range of SSM group addresses to 232.1.1.0/24 on all S9300s. The configurations of
S9300-B, S9300-C, S9300-D, and S9300-E are the same as the configuration of S9300-A, and
are not mentioned here.
[S9300-A] acl number 2000
[S9300-A-acl-basic-2000] rule permit source 232.1.1.0 0.0.0.255
[S9300-A-acl-basic-2000] quit
[S9300-A] pim
[S9300-A-pim] ssm-policy 2000
Step 8 Verify the configuration.
# Run the display pim interface command. You can view the configuration and running status
of PIM on the interface. For example, the PIM information displayed on S9300-C is as follows:
<S9300-C> display pim interface
VPN-Instance: public net
Interface State NbrCnt HelloInt DR-Pri DR-Address
Vlanif102 up 0 30 1 10.110.2.2 (local)
Vlanif400 up 1 30 1 192.168.3.1
# Run the display pim bsr-info command to view information about BSR election on the
S9300s. For example, the BSR information on S9300-A and S9300-E (including the C-BSR
information on S9300-E) is as follows:
<S9300-A> display pim bsr-info
VPN-Instance: public net
Elected AdminScoped BSR Count: 0
Elected BSR Address: 192.168.9.2
Priority: 0
Hash mask length: 30
State: Accept Preferred
Scope: Not scoped
Uptime: 01:40:40
Expires: 00:01:42
C-RP Count: 1
<S9300-E> display pim bsr-info
VPN-Instance: public net
Elected AdminScoped BSR Count: 0
Elected BSR Address: 192.168.9.2
Priority: 0
Mask length: 30
State: Elected
Scope: Not scoped
Uptime: 00:00:18
Next BSR message scheduled at :00:01:42
C-RP Count: 1
Candidate AdminScoped BSR Count: 0
Candidate BSR Address is: 192.168.9.2
