2 - 82 Conversational Part Programming v546CO WinMax Lathe Conversational Part Programming
Figure 2–70. Line Segment with Unknown End and Angle
1 Known Start Point
2 Solution #1
3 Solution #2
4 X Known
5 XY Length Known
6 Y Unknown
7 XY Angle Unknown
Press the Ctrl + arrow console key to program additional Line and
Arc segments for the current data block.
