WinMax Lathe Conversational Part Programming v546CO Conversational Part Programming 2-109
• CORNER RADIUS—defines the radius of the slot end.
• END CAP—accesses selections for the shape of the slot end for the End of the
slot:
• LINE
• APPEND ARC
• INCLUDE ARC
• CORNER RADIUS—defines the coordinate of any one of the four corners of
the slot, which becomes the reference corner.
• Z’ START—defines the location where Plunge Feedrate begins. The feedrate
is set in the Plunge Feed field in the Process tab. The Z’ axis will move in the
physical X direction.
• Z’ BOTTOM—accesses selections for the bottom of the slot and the location
where the Plunge Feed Rate ends. The Z’ axis will move in the physical X
direction.
• AT START (DIA) or (RAD)
• AT END (DIA) or (RAD)
These fields are read-only and are carried over from Tool Setup for the tool specified in
the Process tab.
• TOOL—identifies the tool number that will be used in the part program.
• TOOL OFFSETS—identifies the tool offset and orientation programmed in
Tool Setup that will be used. The tool offset defaults to the same number as
the tool.
• TOOL DIAMETER—contains the tool diameter programmed in Tool Setup for
the current tool. This field is read-only and can only be edited in Tool Setup.
Refer to Start Cap examples above.
