WinMax Lathe Conversational Part Programming v546CO Conversational Part Programming 2-209
The fields on the Transfer block screen Stage 2 tab are:
• 6) Open Main Spindle Chuck—When No is selected, the main spindle chuck
remains closed with the sub-spindle chuck clamping the part. No is the
default. When Yes is selected, the main spindle chuck opens to allow the part
to transfer to the sub-spindle. When Yes is selected, the remaining fields on
this screen are active.
• Dwell (Secs)—identifies the number of seconds the main spindle should
dwell after opening.
• 7) Move to W Position—identifies the W location for the feedrate move.
STORE MACHINE POSITION F7 softkey is available when the cursor is in this
field.
• Rapid to W Position?—Select Yes to move the W axis at rapid feedrate
to a position specified in the Move to W Position field. Select No and the
Feed field becomes active.
• Feed—identifies the W axis feedrate. This field is active when Rapid to W
Position? is No.
• 8) Close Main Spindle Chuck Dwell (Secs)—identifies the number of
seconds the main spindle chuck should dwell after closing.
• 9) Unsync and Stop the Spindles—indicates the last step in the Transfer
data block sequence.
