WinMax Lathe Conversational Part Programming v546CO Conversational Part Programming 2-7
• RAPID TO POSITION—contains the selection for X and Z axis feedrate
toward the X and Z positions. This field is active when either Move To
Position, Move W Only (available for TMX, TMX MY, and TMX MYS Series
machines), or Move Y Only (available for TMX MY and TMX MYS Series
machines) is selected in the WHERE field.
• YES—moves the X and Z axes at the Rapid Traverse feedrate entered in
Program Parameters.
• NO—enables the feedrate to be entered in the FEED (IPM) or (MMPM)
field.
• FEED (IPM) or (MMPM)—contains the feedrate for the programmed tool.
• Enter the feedrate into this field when No is selected in the RAPID TO
POSITION field.
• This field is inactive when Yes is selected in the RAPID TO POSITION field.
• PROGRAM STOP—contains the selection for a stop block:
• NO—continues the program to the next data block after the axes reach
the position specified.
• YES—pauses the program. To continue with the part program after
executing this Position block, press the flashing Start Cycle button.
• OPTIONAL—pauses the program when the Opt Stop console key is
enabled. To continue with the part program after executing this Position
block, press the flashing Start Cycle button.
• STOP THE SPINDLE—contains the selection for a stopping the spindle:
• YES—stops the spindle after the axes reach the position specified.
• No—continues running the spindle.
• TURN OFF COOLANT—
• YES—turns off the coolant.
• No—continues using the coolant.
• DWELL (SECS)—contains the number of seconds the spindle should dwell
after the axes reach the position specified.
• TOOL CHANGE OVERRIDE—select the Tool Change Override check box
(clear is the default) when the tool specified in this data block requires
different tool change settings than those made in Program Parameters
screen, User Defined Tool Change Position settings.
