2 - 6 Conversational Part Programming v546CO WinMax Lathe Conversational Part Programming
• AXIS ORDER—contains the selection for the order the axes will move:
X—specifies the order the turret moves the X axis from the current
position. The default is 0.
• Z—specifies the order the turret moves the Z axis from the current
position. The default is 0.
• W—specifies the order the W axis (Programmable Tailstock or Sub-
spindle) moves from the current position. The default is 0. This field
appears on TMX, TMX MY, and TMX MYS Series machines.
• Y—specifies the Y-axis motion from the current position. The default is 0.
This field appears on TMX MY and TMX MYS Series machines.
When the cursor is in any of the Axis Order fields, these selections are
available for entering the order of axes movement:
•DON’T MOVE (0)
•FIRST (1)
• SECOND (2)
• THIRD (3)
• FOURTH (4)
• SIMULTANEOUS
• C AXIS ORDER—contains the order selection for the C Axis to move relative
to the other axes. This field is active when either Move Turret Home, Move to
Position, or Move All Home is selected in the WHERE field. This field is
available for TMM, TMX MY, and TMX MYS Series machines.
• No C
• C FIRST
• C LAST
• SIMULTANEOUS
• C (DEG)—contains the degree of the angle for the C Axis. This field is active
when Move Turret Home, Move to Position, or Move All Home is selected in
the Where field and either C First, C Last C Middle, or Simultaneous is
selected in the C Axis Order field. This field is available for TMM, TMX MY, and
TMX MYS Series machines.
An axis must be selected in the axis order field when either Move
Turret Home, Move To Position, or Move All Home is selected in the
Where field.
