3. Mount the rectifier shelf. Note the following prerequisites:
•
If more than one shelf is being mounted, first mount the bottom shelf.
•
The shelf should have a minimum of 5 cm between the back of the shelf and any
obstruction to allow for air flow out the back of the rectifier.
•
Adjust mounting brackets, as needed, for different front to back depths.
•
Verify that all cabling length is sufficient for all connections.
4. Verify which mounting brackets you need to use for the rack size, and position the
shelf.
Secure the shelf to the rack with four mounting screws.
207Copyright © 2019, Juniper Networks, Inc.
Chapter 8: AC Rectifier (External)
