Page #171 background imageLoading...
Page #171 background image
CHAPTER 9
Pinout Specifications
Console Port Connector Pinout Information on page 149
Mini-USB Port Pinout Specifications on page 150
USB Port Specifications for an EX Series Switch on page 150
RJ-45 Management Port Connector Pinout Information on page 152
RJ-45 Port, QSFP+ Port, SFP+ Port, and SFP Port Connector Pinout
Information on page 152
RJ-45 to DB-9 Serial Port Adapter Pinout Information on page 157
Console Port Connector Pinout Information
The console port on a Juniper Networks device is an RS-232 serial interface that uses an
RJ-45 connector to connect to a console management device. The default baud rate for
the console port is 9600 baud.
Table 78 on page 149 provides the pinout information for the RJ-45 console connector.
NOTE: If your laptop or PC does not have a DB-9 male connector pin and you
want to connect your laptop or PC directly to a device, use a combination of
the RJ-45 to DB-9 female adapter and a USB to DB-9 male adapter. You
must provide the USB to DB-9 male adapter.
Table 78: Console Port Connector Pinout Information
DescriptionSignalPin
Request to sendRTS Output1
Data terminal readyDTR Output2
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
149Copyright © 2017, Juniper Networks, Inc.
