Juniper EX4300 Hardware Guide

You can install an uplink module horizontally in the uplink module slot on the front panel
of the switch. By installing an uplink module, you add more ports to your switch, thereby
increasing the port density of the switch.
Table13 on page32 shows the uplink modules supported on 24-port and 48-port EX4300
switches, their descriptions, and the Junos OS release in which the models were released.
Table 14 on page 32 shows the uplink modules supported on 32-port EX4300 switches,
their descriptions, and the Junos OS release in which the models were released.
Table 13: Uplink Modules in 24-Port and 48-Port EX4300 Switches
First Junos OS
ReleaseSupported EX4300 SwitchesDescriptionModel Number
Uplink
Module
Name
Junos OS Release
13.2X50-D10
•
EX4300-24T
•
EX4300-24P
•
EX4300-48T
•
EX4300-48T-AFI
•
EX4300-48P
•
EX4300-48T-DC
•
EX4300-48T-DC-AFI
Thisuplink module can house
up to four SFP+ transceivers,
four SFP transceivers, or a
combination of four SFP+ and
SFP transceivers. You can
also configure these ports as
Virtual Chassis ports (VCPs)
and use them to connect the
switch in a Virtual Chassis or
a VCF configuration by using
SFP+ transceivers.
EX-UM-4X4SFP4-port
10-Gigabit
EthernetSFP+
uplink module
Junos OS Release
13.2X51-D26
•
EX4300-24T-S
•
EX4300-24P-S
•
EX4300-48T-S
•
EX4300-48P-S
Table 14: Uplink Modules in 32-Port EX4300 Switches
First Junos OS Release
Supported EX4300
SwitchesDescriptionModel Number
Uplink Module
Name
Junos OS Release
13.2X51-D15
•
EX4300-32F
•
EX4300-32F-DC
This uplink module can house up
to two QSFP+ transceivers. You
can also configure these ports as
VCPs and use them to connect
the switch in a Virtual Chassis or
a VCF configuration.
EX-UM-2QSFP2-port
40-Gigabit
Ethernet QSFP+
uplink module
Junos OS Release
13.2X51-D26
•
EX4300-32F-S
Junos OS Release
13.2X51-D15
•
EX4300-32F
•
EX4300-32F-DC
This uplink module can house up
to eight SFP+ transceivers, eight
SFP transceivers, or a
combination of eight SFP+ and
SFP transceivers. You can also
configure these ports asVCPs and
use them to connect the switch
in a Virtual Chassis or a VCF
configuration by using SFP+
transceivers.
EX-UM-8X8SFP8-port
10-Gigabit
Ethernet SFP+
uplink module
Junos OS Release
13.2X51-D26
•
EX4300-32F-S
Copyright © 2017, Juniper Networks, Inc.32
EX4300 Switch Hardware Guide

Juniper EX4300 Specifications

General

Model	EX4300
Virtual Chassis	Yes, up to 10 members
Layer 3 Routing	Yes
10GBASE SFP+ Ports	4
Jumbo Frames	9216 bytes
MAC Address Table Size	32, 000
Operating System	Junos OS
Uplink Ports	4 x 10GBASE SFP+
Power Supply	AC or DC options
Operating Temperature	0°C to 45°C (32°F to 113°F)
Input Voltage	100-240V AC
Operating Relative Humidity	5 to 90% RH, non-condensing
Management Options	CLI, Web UI, Junos Space
Redundancy	Yes, power supply and fans
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	24 or 48
