Table 78: Console Port Connector Pinout Information (continued)
DescriptionSignalPin
Receive dataRxD Input6
Data carrier detectCD Input7
Clear to sendCTS Input8
Related
Documentation
Connecting a Device to a Management Console by Using an RJ-45 Connector on page 194•
• Configuring the Console Port Type (CLI Procedure)
Mini-USB Port Pinout Specifications
If your management host (laptop or PC) does not have a DB-9 male connector pin or an
RJ-45 connector pin but has a USB port, you can connect your management host to the
Mini-USB Type-B console port by using a cablethat has a standardType-A USB connector
on one end and a Mini-USB Type-B (5-pin) connector on the other end.
The Mini-USB Type-B console port uses a Mini-USB Type-B connector to connect to a
console management device. The default baud rate for the console port is 9600 baud.
Table 79 on page 150 provides the pinout information of the Mini-USB Type-B console
port.
Table 79: Mini-USB Type-B Console Port Pinout Information
DescriptionSignalPin
+5 VDCVCC1
Data -D-2
Data +D+3
Could be not connected (N/C), connected to ground (GND), or used as an attached device
presence indicator
N/CX
GroundGND4
Related
Documentation
Management Cable Specifications on page 146•
USB Port Specifications for an EX Series Switch
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all EX Series switches:
Copyright © 2017, Juniper Networks, Inc.150
EX4300 Switch Hardware Guide
